Cat6A Tool-Free RJ45 Keystone Jacks (10-Pack) | Unshielded, Shuttered, Black for 10GbE Networks

Achieve superior network performance with our 10-pack of black Cat.6A Unshielded Toolless Keystone Jacks. Designed for simplicity and efficiency, these jacks allow for quick and reliable terminations without the need for a punch-down tool. The intuitive design is perfect for installers of all skill levels, ensuring a solid connection every time. Whether you're upgrading your home network, office infrastructure, or setting up a data centre, these jacks provide the high-speed connectivity required for today's demanding applications.

Constructed with a robust zinc die-cast housing plated in nickel, these keystone jacks are built for durability and long-term performance. The high-quality internal components, including 50U" gold-plated contacts, ensure optimal signal integrity for 10-Gigabit Ethernet speeds. An integrated shutter automatically protects the jack from dust and debris when not in use , prolonging the life of the connection point and maintaining performance.

These jacks offer broad compatibility, accommodating solid core cables from 23AWG to 26AWG. Clear, easy-to-read colour coding for both T568A and T568B wiring standards is provided, eliminating guesswork and preventing wiring errors during installation. This pack of ten provides excellent value, making it an ideal choice for larger projects or for keeping spares on hand for future network expansions or repairs.

Engineered to meet rigorous industry standards, including ANSI/TIA-568.2-D and ISO/IEC 11801-1, these jacks are a reliable foundation for any high-performance network. With a durability rating of 200 termination cycles and a plug insertion life of over 750 cycles , you can trust these keystone jacks to provide a stable and consistent connection for years to come.

FEATURES

• Toolless termination for fast and easy installation
• Cat.6A performance for 10-Gigabit Ethernet networks
• Durable zinc die-cast housing with nickel plating
• Integrated dust shutter for contact protection
• Supports both T568A and T568B wiring standards
• Compatible with 23AWG to 26AWG solid core cables
• High durability with 200 termination cycles
• Convenient 10-Pack

SPECIFICATIONS

• Current Rating: 1.5A
• Insulation Resistance: >500MΩ
• Contact Resistance: ≤10mΩ
• DC Resistance: ≤0.1Ω
• Voltage Endurance: DC1000V/AC750V for 1 min
• Plug Insertion Life: ≥750 Cycles
• Termination Durability: 200 Cycles
• Plug & Jack Contact Force: ≥100 Grams
• Plug Retention Force: ≥11lbf
• Housing: Zinc Die-Casting with Nickel Plating
• Plastic Parts: High quality engineering plastic
• PCB: FR-4, 1.2mm thickness
• Contact Compatibility: 23AWG to 26AWG Solid
• Operating Temperature: -10°C to 60°C
• Operating Humidity: 10%~90%RH
• Storage Temperature: -40°C to 68°C
• Standards: ANSI/TIA-568.2-D , ISO/IEC 11801-1 , RoHS Compliant

WARRANTY

3-Year Limited Warranty
